Alumina Ceramic Lined Stainless Steel Elbow
Product characteristics
Wear resistance: under the same conditions, 10 times wear-resistant than ordinary pipes;
Corrosion resistance: ceramic lining and inorganic adhesive can resist acid and alkali corrosion;
Medium temperature resistance: it can run at 350℃ for a long time, and the general working conditions can be met;
The inner and outer walls are smooth, and the air flow is smooth: the smooth surface enables the material to pass freely without hanging and blocking the material;
Easy to install: 1/3 lighter than ordinary pipes, easy to handle, save manpower, easier to install, faster, can easily set up higher pipes;
Reduce the load of support and hanger equipment and save material cost.
Chemical index
|
Item |
92alumina |
95alumina |
96alumina |
99alumina |
|
Al2O3 |
92% |
95% |
96% |
99% |
|
Na2O |
≤0.4% |
≤0.2% |
≤0.1% |
≤0.15% |
|
K2O |
≤1.06% |
≤0.5% |
≤0.54% |
≤0.25% |
|
Fe2O3 |
≤0.01% |
≤0.01% |
≤0.01% |
≤0.01% |
|
SiO2 |
≤4.7% |
≤3.28% |
≤2.5% |
≤0.2% |
Physical index
|
Item |
92alumina |
95alumina |
96alumina |
99alumina |
|
Density (g/cm3) |
≥3.62 |
≥3.68 |
≥3.8 |
≥3.9 |
|
Moh’s hardness (Grade) |
9 |
9 |
9 |
9 |
|
Vickers hardness (HV10) |
1200 |
1300 |
1400 |
1450 |
|
Bending strength (Mpa) |
260 |
300 |
380 |
420 |
|
Breaking tenacity (Mpa.M1/2) |
3 |
3.2 |
4 |
4.5 |
|
Wear loss |
1.6g |
1.2g |
0.7g |
0.6g |
Product specification
Our pipe sizes are φ20-300, which can be customized.
Chemshun Advantage
Our products have been exported to Australia, Chile, Peru, South Africa, the United States, Russia, Japan, Indonesia and other countries, we can provide wear-resistant ceramic technology solutions, will provide suitable for your requirements of products and quality service.
